| Whole-door thermal performance |
Target a certified whole-door U-value of approximately
≤ 1.6 W/m²·K for many temperate applications.
For energy-efficient projects, a lower value is preferable.
|
Complete test report showing the U-value of the assembled door, including the frame, glass, seals and panels. Do not rely only on the center-of-glass value.
|
Whole-door performance is more representative of actual heat loss than glass-only data and helps buyers compare products fairly across markets.
|
| Insulating glass configuration |
Low-emissivity double glazing with an inert-gas cavity is common for general climates. Triple glazing may be appropriate for colder regions, subject to frame and hardware compatibility.
|
Glass build-up, cavity thickness, Low-E coating position, gas-fill declaration, spacer type and factory quality-control records.
|
Glass configuration affects insulation, condensation risk, weight, price and the required load capacity of hinges, rollers and tracks.
|
| Solar heat gain control |
Select the solar heat gain coefficient according to climate and orientation. A lower SHGC is generally useful in hot, highly exposed locations; a higher SHGC may benefit passive solar heating in colder climates.
|
NFRC or equivalent laboratory data for SHGC, visible transmittance and U-value, plus the exact glass specification used in production.
|
Correct solar control can reduce cooling loads while maintaining useful daylight. One glass specification is not ideal for every country or façade orientation.
|
| Air permeability |
Prefer a tested classification under EN 12207 or a measured result under ASTM E283. For exposed façades, request a high-performing classification rather than an unverified “airtight” claim.
|
Air-leakage test report identifying the complete door size, test pressure, opening configuration and laboratory.
|
Poor air control can increase drafts, energy use, moisture movement and indoor discomfort, especially in tall or wind-exposed buildings.
|
| Water tightness |
Require testing under EN 12208 or ASTM E331. The required rating should reflect local rainfall, wind exposure, building height and installation conditions.
|
Water-penetration report for the complete bifold assembly, including drainage details, sill design and threshold configuration.
|
A high-quality frame can still leak if the sill drainage, gaskets or installation interface is poorly designed.
|
| Wind-load resistance |
Require structural testing under EN 12210 or ASTM E330. The design pressure must be calculated for the project location, opening size and building exposure.
|
Structural test data, maximum panel dimensions, mullion or post details, allowable deflection criteria and anchoring requirements.
|
Wind performance depends on the complete system, not just the aluminium profile. Larger panels require careful structural verification.
|
| Safety glass protection |
Use safety glazing where required by local building regulations. Tempered glass is commonly used for impact resistance; laminated glass helps retain fragments after breakage.
|
Glass safety classification, thickness, heat-treatment or lamination records, edge-quality controls and compliance documentation such as EN 12150 or EN 14449 where applicable.
|
Correct safety glazing reduces injury risk and supports compliance in doors located near floors, walkways and large glazed openings.
|
| Acoustic insulation |
An indicative target of approximately
Rw 30–40 dB
may suit many residential applications, but traffic-heavy locations may require a project-specific acoustic design.
|
Laboratory sound-reduction report for the complete door, stating the tested size, glass composition and acoustic rating.
|
Acoustic performance is strongly influenced by glass thickness, laminated interlayers, gaskets, frame joints and installation quality.
|
| Frame and thermal-break design |
Prefer thermally broken aluminium for demanding exterior applications. Confirm that the thermal barrier is continuous through the frame, sash and threshold.
|
Profile cross-sections, thermal-break material and width, corner-joint details, threshold drawings and assembled-door thermal calculations.
|
A continuous thermal break helps limit cold bridging, interior condensation and temperature variation around the opening.
|
| Panel size and operating weight |
Common residential panel widths are often approximately
600–1,200 mm,
but maximum dimensions depend on glass weight, profile strength, hardware and wind loading.
|
Maximum tested panel width and height, maximum sash weight, glass thickness limits, panel configuration drawings and required installation tolerances.
|
Oversized panels may reduce ease of operation and service life if the rollers, hinges, tracks and frame are not engineered for the total load.
|
| Hardware durability |
For frequently used openings, request cycle testing of at least
10,000 operating cycles
under EN 1191 or an equivalent test method.
|
Hardware cycle-test results, corrosion-resistance information, roller material, adjustment range, replacement-part availability and maintenance instructions.
|
Bifold doors place repeated loads on hinges, rollers and tracks. Serviceable hardware is essential for long-term operation.
|
| Threshold and accessibility |
Choose a low or flush threshold only when the drainage design, water-performance test and local accessibility requirements are satisfied.
|
Threshold section, drainage path, sill flashing details, weather-seal arrangement and tested water-performance data for the selected threshold.
|
Lower thresholds improve accessibility but may require more precise waterproofing, falls, drainage and installation workmanship.
|
| Corrosion resistance |
For coastal or high-humidity locations, specify suitable powder coating or anodizing and request a documented corrosion-resistance process.
|
Coating thickness, pretreatment method, finish standard, salt-spray or equivalent test evidence and written cleaning requirements.
|
Marine air, de-icing salts and industrial pollutants can shorten the life of exposed aluminium finishes and hardware.
|
| Quality-control system |
Prefer suppliers with documented incoming-material inspection, in-process checks, final dimensional inspection and traceable batch records.
|
Quality manual, inspection checklist, glass traceability process, nonconformity records, calibration certificates and pre-shipment inspection procedure.
|
Consistent production control reduces variation between samples and mass-production deliveries.
|
| Installation and technical support |
Require project-specific shop drawings, installation instructions, fixing schedules, drainage details and defined tolerances before production.
|
Approved drawings, interface details, packaging plan, installation training or support, commissioning checklist and after-sales response process.
|
Air, water, thermal and operating performance can be seriously reduced by incorrect installation even when the door itself has passed laboratory testing.
|
| Documentation and market compliance |
Select a supplier able to provide documents required by the destination market, including test reports, declarations, material data and installation guidance.
|
Product datasheet, complete test reports, safety-glazing documentation, environmental or material declarations where required, packing list and export documents.
|
Complete documentation supports customs clearance, local approval, tender evaluation, warranty claims and future replacement work.
|
| Warranty and spare-parts planning |
Confirm written warranty terms for profiles, glass, finish, seals and hardware separately. Establish a practical spare-parts supply period before placing the order.
|
Warranty duration and exclusions, response times, replacement-part list, hardware coding system and procedure for reporting defects.
|
A clear after-sales arrangement is particularly important for international buyers who may face long shipping times and local service limitations.
|
